A unique selection of reducers
We stock concentric and eccentric reducers made of steel, stainless steel and forged materials in accordance with EN10253-2/-4, DIN 2616 and ASME B16.9. Our stock range includes reducers in materials such as P235GH through 16Mo3 to P355N/NL/NH and 10CrMo9-10 or WPB through WP11, WP22 and WP5 to high yield grades such as WPHY52 as well as in materials such as 1.4301 through 1.4404 to 1.4462 or WP304 through WP316L and WP310S.
Steel reducers in accordance with EN and DIN are available from stock with a reduced rate of utilization (EN 10253-2 / EN 10253-4 type A or DIN 2616 part 1), as well as with a full rate of utilization (EN 10253-2 / EN 10253-4 type B or DIN 2616 part 2) and are immediately available from stock.
TÜV and PED approved
All manufacturers of our stock products are ISO 9001 certified and PED approved. We only supply elbows and fittings according to EN from TÜV- and PED-approved manufacturers with MTC EN 10204-3.1 or MTC 3.2 TÜV in accordance with the applicable AD data sheets.
Carbon steel reducers
Products materials: P235GH TC1-TC2, P265GH, P245GH, 10CrMo9-10, 13CrMo4-5, 16Mo3+N, P355NH, P355NL1 etc.
We stock carbon steel reducers as follows:
| EN 10253-2 Type A, 10253-2 Type B | DIN 2616 Part 1, 2616 Part 2 | ASME B16.9 |
|---|---|---|
| Range of sizes
21.3 mm – 508.0 mm | Range of sizes
21.3 mm – 508.0 mm | Range of sizes
1/2" –20" |
| Range of wall thicknesses Range 2.0 - 40.0 | Range of wall thicknesses Range 2.0 - 40.0 | Range of wall thicknesses SCH10 – XXS |
| Design concentric eccentric | Design concentric eccentric | Design concentric eccentric |
Stainless steel reducers
Products materials: 1.4301-X5CrNi18-10, 1.4306-X2CrNi19-11, 1.4541-X6CrNiTi18-10, 1.4404-X2CrNiMo17-12-2 etc.
We stock reducers in a wide range of stainless-steel materials and designs.
| EN 10253-4 Type A, 10253-4 Type B | DIN 2616 Part 1, 2616 Part 2 | ASME B16.9 |
|---|---|---|
| Range of sizes
21.3 mm – 508.0 mm | Range of sizes
21.3 mm – 508.0 mm | Range of sizes
1/2" – 20" |
| Range of wall thicknesses Range 2.0 - 40.0 | Range of wall thicknesses Range 2.0 - 40.0 | Range of wall thicknesses SCH10S – XXS |
| Type concentric eccentric | Type concentric eccentric | Type concentric eccentric |
